Stronger, Last Longer, More control

  • Stainless Steel parts
  • Precise 3 way saliva restriction system
  • 5 year warranty*

2023 M1800HD models are available at a reduced price per unit for $4500 + GST for assembled and $4175 + GST for flat packed. Hurry, stock is limited. Standard reward program discounts apply. Call 1300 88 15 75 to enquire**

**These feeders do not include the new design changes and upgrades

Weight:500kg
Length :
3610mm
Width:
1670mm
Height SettingFill HeightRoof peak height
Dimensions at sheep height:
1460mm1730mm
Dimensions at cattle height:
1660mm1930mm
Flat-pack dimensions:2445 x 1160 x 325 (LxWxH)
Feed Volume:1800 litres
Feed weight – wheat/lupins:1400kg
Feed weight – barley/pellets:1150kg
Feed weight – oats:900kg
Ewes or lambs (paddock):200-250
Ewes or lambs (feedlot):
120-150
Ewes and lambs (creep feeding):
 200-250 combined
Cattle or calves (paddock):
40-50
Cattle (feedlot):30-35
Goats (paddock):200-250
Deer (paddock):120-150
Pigs:120-150
  • NEW numbered Adjuster Guard Handle design
  • NEW Cleaning Tool and Tube Spanner locations
  • NEW Flow Assist
  • NEW Adjuster Lock
  • Upgraded Roof Pivot
  • Reinforced stainless steel troughs
  • Reinforced stainless steel upper adjusters
  • Reinforced stainless steel lower adjusters
  • 2x adjuster guards standard
  • Adjuster guard housing when not in use
  • 4x 40mm SHS stands
  • Channel reinforced trough
  • Z275 sheetmetal
  • 45 degrees angled trough
  • 100mm feed flow area
  • Rain protection reinforcing
  • Side wall bracing
  • Channel roof pivot bracket
  • 6x adjuster braces
  • Dual tab adjuster braces
  • 4x locking bolts on the lower adjusters
  • Adjuster guard locking system
  • Dual positioned adjuster guard for dusty feeds
  • 4x 75mm round sight glasses
  • Vertical sidewall bracing for easy feed flow
  • 2x volume stickers
  • Adjuster feeder height in just 30 minutes
  • Cleaning tool supplied
  • Tube spanner supplied
  • Secure housing for tools
  • 2x new tyres
  • 2x safety chains supplied
  • 2380mm trough length
  • Painted notch system on the adjusters
  • Drop lock pin roof locking system
  • Deep 110mm trough depth
  • Gutters on side walls drain out of feeder
  • Weather protection over the troughs
  • Reinforced roof edges
  • Mineral attachment option
  • Calf creep feeding gate option
  • Lamb creep feeding panel option
  • Rubber mat option
  • 5 year extended warranty
  • 30 day money back guarantee
  • Standard operating procedure supplied
  • User guide supplied
  • Trial reports available
  • Purchase flat-packed or assembled
